SN | Project | Name | Parameter |
1 | structural style | Number of shaft heads: | 1 axis |
Station: | 1 workstation | ||
Table size: | 1250mm*900mm | ||
Workbench carrying capacity: | 500kg . | ||
2 | Spindle mechanism | Control method: | Variable frequency motor+synchronous toothed belt |
Spindle motor: | 2.2 KW | ||
Processing aperture range: | Φ 2 - Φ60m (optional outside the range) | ||
Variable speed range: | 50-3000rpm (continuously variable speed) | ||
3 | Stroke mechanism | Control method: | Servo motor+ball screw |
Stroke speed MAX: | 40m/min | ||
Stroke length MAX: | 350mm | ||
4 | Feed mechanism | Control method: | Servo motor+ball screw |
Feed form: | Constant feed | ||
Feed resolution: | 0.1um | ||
5 | other | Equipment weight: | About 2.5 tons |
Equipment size (length x width x height): | 1500*1500*2350 | ||
Noise standard: | Less than 75 decibels under continuous loading peak in a standard factory environment | ||
Power Supply: | Three phase AC: 380V50HZ | ||
Environmental conditions: | Temperature -10~+45C | ||
Temperature<72% |
SN | Project | Name | Parameter |
1 | structural style | Number of shaft heads: | 1 axis |
Station: | 1 workstation | ||
Table size: | 1250mm*900mm | ||
Workbench carrying capacity: | 500kg . | ||
2 | Spindle mechanism | Control method: | Variable frequency motor+synchronous toothed belt |
Spindle motor: | 2.2 KW | ||
Processing aperture range: | Φ 2 - Φ60m (optional outside the range) | ||
Variable speed range: | 50-3000rpm (continuously variable speed) | ||
3 | Stroke mechanism | Control method: | Servo motor+ball screw |
Stroke speed MAX: | 40m/min | ||
Stroke length MAX: | 350mm | ||
4 | Feed mechanism | Control method: | Servo motor+ball screw |
Feed form: | Constant feed | ||
Feed resolution: | 0.1um | ||
5 | other | Equipment weight: | About 2.5 tons |
Equipment size (length x width x height): | 1500*1500*2350 | ||
Noise standard: | Less than 75 decibels under continuous loading peak in a standard factory environment | ||
Power Supply: | Three phase AC: 380V50HZ | ||
Environmental conditions: | Temperature -10~+45C | ||
Temperature<72% |
