One、Equipment parameters
Processing aperture range | Φ3-Φ120mm |
Processing depth | 0-280mm (Optional 400mm) |
Spindle speed | 250-3000 rpm variable frequency stepless adjustment |
Host motor | 1.5KW, 3-100HZ variable frequency motor |
STROKE LENGTH | 0-170 |
Stroke speed | 80-310 times/minute variable frequency stepless adjustment |
Stroke Motor | 0.75KW |
Shutdown braking of the spindle and stroke | Frequency converter electronic braking |
Oil pump motor | 0.12KW |
Fuel tank capacity | 50L |
Machine weight | 486KG |
Overall dimensions | 1000*1390*1400mm |
power supply | 380V, 50HZ, three-phase four wire |
Two、 Equipment processing accuracy
1. Roundness: 0.004mm;
2. Straightness: 0.006mm;
3. Roughness: sRa0.2um.
Three、 Description of the main points of the equipment
1. Φ 3- Φ Large machining range of 120mm.
2. NSK main bearing ensures reliability and stability.
3. Dual variable frequency continuously variable speed, with arbitrary adjustment of spindle speed and stroke speed.
4. It has size control functions such as "manual, zero, and time". The zero honing adopts electric induction technology, and is equipped with a manual unlocking device and a zero adjustment device.
5. The equipment can achieve honing of through holes and blind holes.
One、Equipment parameters
Processing aperture range | Φ3-Φ120mm |
Processing depth | 0-280mm (Optional 400mm) |
Spindle speed | 250-3000 rpm variable frequency stepless adjustment |
Host motor | 1.5KW, 3-100HZ variable frequency motor |
STROKE LENGTH | 0-170 |
Stroke speed | 80-310 times/minute variable frequency stepless adjustment |
Stroke Motor | 0.75KW |
Shutdown braking of the spindle and stroke | Frequency converter electronic braking |
Oil pump motor | 0.12KW |
Fuel tank capacity | 50L |
Machine weight | 486KG |
Overall dimensions | 1000*1390*1400mm |
power supply | 380V, 50HZ, three-phase four wire |
Two、 Equipment processing accuracy
1. Roundness: 0.004mm;
2. Straightness: 0.006mm;
3. Roughness: sRa0.2um.
Three、 Description of the main points of the equipment
1. Φ 3- Φ Large machining range of 120mm.
2. NSK main bearing ensures reliability and stability.
3. Dual variable frequency continuously variable speed, with arbitrary adjustment of spindle speed and stroke speed.
4. It has size control functions such as "manual, zero, and time". The zero honing adopts electric induction technology, and is equipped with a manual unlocking device and a zero adjustment device.
5. The equipment can achieve honing of through holes and blind holes.
